Technical elements of automatic wet wipes machine equipment

1. An eccentric frame is provided at both ends of the upper knife roller, the eccentric frame is rotatably connected to the frame, and a center hole is provided on the eccentric frame. Not coincident, the center line of the upper knife roller and the center line of the center hole coincide, and the eccentric frame is provided with a centering component.

By adopting the above technical solution, the eccentric frame is rotatably connected to the frame, and the center line of the center hole opened on the eccentric frame does not coincide with the rotation center line of the eccentric frame, so that the position of the upper knife roller can be adjusted when the eccentric frame is rotated. Match the cutters on the upper cutter roll with the cutters on the lower cutter roll.

12-lanes wet wipes machine

2. The self-aligning assembly includes an incomplete gear and an adjustment gear. The eccentric frame is provided with an arc-shaped groove, and bolts are arranged in the arc-shaped groove. The adjustment gear is rotatably connected to the frame. Coaxially fixed on the eccentric frame, the adjusting gear meshes with the incomplete gear.

By adopting the above technical solution, the incomplete gear is matched with the adjusting gear. When the adjusting gear is rotated, the incomplete gear rotates, and the incomplete gear drives the eccentric frame to rotate for adjustment, and then the eccentric frame is fixed by bolts. It is more convenient to rotate, which makes it easier to adjust the feed position.

3. The cloth feeding roller, the liquid spraying pipe and the two cloth clamping rollers of the liquid spray device. The wet tissue cloth passes through the cloth feeding roller and the two cloth clamping rollers in turn. The liquid spraying pipe is located in the cloth feeding roller and the cloth clamping roller. The liquid spray pipe is provided with a plurality of spray heads facing the wet cloth, and the two ends of the liquid spray pipe are respectively provided with a lifting piece, and the lifting piece drives the liquid spray pipe relative to the wet tissue cloth. The length direction of the wet wipe fabric moves back and forth.

By adopting the above technical solution, a lifting member is installed on the liquid spray pipe, and when the lifting member is working, the lifting member can drive the nozzle to reciprocate along the length direction of the wet tissue cloth, so that the wet tissue cloth can be added liquid for many times, improving the Wetting effect on the cloth for wet wipes.

4. Non-woven humidification equipment for wet wipes production

It is characterized in that: it includes a frame and an unwinding device, a cloth impregnation device and a winding device arranged on the frame, the cloth dipping device is arranged between the unwinding device and the winding device, and is stored by a storage device equipped with humidifying liquid. It consists of a liquid tank and a cloth pressing roller. The cloth pressing roller is laterally fixed inside the liquid storage tank. The unwinding device is composed of an unwinding disk, a guide roller and a tension roller. It is composed of a traction roller and a hydraulic roller, a rotating shaft is arranged at the center of the reel, and the motor drives the rotating shaft to rotate through a chain drive.
